The joint was secured using an M8×1.25×25 mm flanged hex head bolt (property class 10.9, zinc-plated), tightened to a torque of 25 N·m
To ensure structural integrity under dynamic loading, the test fixture was assembled using M8×1.25×25 mm flanged hex head bolts conforming to ISO property class 10.9. Each bolt was zinc-plated to provide basic corrosion protection without compromising tensile strength. The integrated flange eliminated the need for separate washers and helped distribute clamping force more evenly across the joint.
The joint was secured using an M8×1.25×25 mm flanged hex head bolt (property class 10.9, zinc-plated), tightened to a torque of 25 N·m
To ensure structural integrity under dynamic loading, the test fixture was assembled using M8×1.25×25 mm flanged hex head bolts conforming to ISO property class 10.9. Each bolt was zinc-plated to provide basic corrosion protection without compromising tensile strength. The integrated flange eliminated the need for separate washers and helped distribute clamping force more evenly across the joint.
